New type 40mm 100w ac micro motor

FOB Reference Price:Get Latest Price
$90.00 - $125.00 / Pieces | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 30 >30
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Model Number:
40ST-M00330
Output Power:
100 w
Type:
Servo Motor
Frequency:
50 hz
Phase:
Single-phase
Certification:
CE
Protect Feature:
Drip-proof
AC Voltage:
208-230 / 240 V
Efficiency:
IE 3
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
packed in plywood case or carton
Port
China
Lead Time :
Quantity(Pieces) 1 - 30 >30
Est. Time(days) 7 To be negotiated

New type 40mm 100w ac micro motor has a very compact structure and attractive appearance. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance.



They are widely used in digit control machine tools, laser processing machines, computer embroidery machines, textile machinery, printing machinery, packaging machinery, markers, engraving machines, winding machines, three-coordinates measuring machines, XYZ three- dimensional tables, industrial robots, medical equipment, woodworking machinery, ceramic machinery and other industries.



The specification of new type 40mm 100w ac micro motor



Motor model

40ST-M00330

Rated power(W)

100

Rated voltage(V)

220

Rated current(A)

0.9

Rated speed(rpm)

3000

Holding torque(N.m)

0.32

Peak torque(N.m)

0.64

Voltage constant(V/krpm)

32.8

Torque coefficient(N.m/A)

0.36

Rotor inertia(Kg.m2)

0.051×10-4

Phase Resistance(Ω)

34

Phase Inductance(mH)

40

Machanical time-constant(Ms)

1.18

Weight(Kg)

0.47

Encoder line number(PPR)

2500

Insulation class

                                            Class B(130 centigrade)

Safety class

IP65

The operating

of Environmental Conditions

                                        Temperature:-20 ~ +50 centigrade

                                        Humidity: Below 90%RH No dewing

Motor winding

plue

Winding lead wire

U

V

W

PE



Plug serial numberr

2

3

4

1



Encoder plug

Signallead wire

5V

0V

A+

B+

Z+

A-

B-

Z-

U+

V+

W+

U-

V-

W-

PE

Plug serial number

2

3

4

5

6

7

8

9

10

11

12

13

14

15

1





Please contact with us for more detailed technical information.



We can make according to your requirements.
