47 oz-in stepper motor

FOB Reference Price:Get Latest Price
$5.80 - $6.50 / Pieces | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 30 >30
Est. Time(days) 5 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Model Number:
FHB42-38
Step Angle(degrees):
0.9
Holding Torque:
47 oz-in
Phase:
2
Type:
Hybrid
Current / Phase:
1.2A
Certification:
CE
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
packed in plywood case or carton
Port
China
Lead Time :
Quantity(Pieces) 1 - 30 >30
Est. Time(days) 5 To be negotiated

47 oz-in stepper motors are the brushless, synchronous electris motor that can divide a full rotation into a large number of steps. The motor's position can be controlled precisely, without any feedback mechanism.



Electric Parameters:



Model

FHB42-38

Step Angle(°)

1.8

Length L(mm)

38

Holding torque(N.m)

0.26

Current (A/phase)

1.2

Resistance(Ω)

3.3

Inductance (mH)

3.2

Rotor inertia (g.cm2)

54

Weight (kg)

0.28

Step accuracy

5%

Temperature

   80 degree   Max

Environmental temperature

   -20 ~ + 50 degree

Insulation resistance

 100MΩ   Min 500 V DC

Withstand voltage

 500V AC 1minute



Please contact with us for more detailed technical information.



We can design according to clients' requirements.
