electric spindle motor

FOB Reference Price:Get Latest Price
$395.00 - $485.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Model Number:
180ST-M35015
Usage:
Universal
Protect Feature:
Waterproof
Function:
Control
Structure:
Synchronous Motor
Phase:
Three Phase
Speed:
Variable Speed
Power:
AC
Shape:
Square
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Packed in plywood case or carton
Port
China
Lead Time :
within 7 days



Electric spindle motor has a very compact structure and attractive appearance. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance.



They are widely used in digit control machine tools, laser processing machines, computer embroidery machines, textile machinery, printing machinery, packaging machinery, markers, engraving machines, winding machines, three-coordinates measuring machines, XYZ three- dimensional tables, industrial robots, medical equipment, woodworking machinery, ceramic machinery and other industries.



The specification of gear motor



Motor model

180ST-M35015

Rated power(KW)

5.5

Rated voltage(V)

380

Rated current(A)

12

Rated speed(rpm)

1500

Holding torque(N.m)

35

Peak torque(N.m)

70

Voltage constant

(V/krpm)

181

Torque coefficient(N.m/A)



2.9

Rotor inertia(Kg.)

8.6×10-3

Phase Resistance(Ω)

0.62

Phase Inductance

(mH)

4

Machanical time-constant

(Ms)

6.45

Weight(Kg)

30.5

Encoder line number

(PPR)

2500

Insulation class

Class B(130)

Safety class

IP65

The operating

of Evironmental Conditions

                       Temperature: -20 +50

                       HumidityBelow 90%RH No dewing

Motor winding

plue

Winding lead wire

U

V

W

PE

Plug serial numberr

2

3

4

1

Encoder plug

Signal lead wire

5V

0V

A+

B+

Z+

A-

B-

Z-

U+

V+

W+

U-

V-

W-

PE

Plug serial number

2

3

4

5

6

7

8

9

10

11

12

13

14

15

1





Please contact with us for more detailed technical information.



We can make according to your requirement.
