85mm 2Nm hybrid step motor

FOB Reference Price:Get Latest Price
$29.00 - $39.00 / Piece | 1 Piece/Pieces (Min. Order)
Step Angle(degrees):
1.2
Holding Torque:
2NM
Lead Time:
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 5 Negotiable
Customization:
Customized logo (Min. Order: 1 Pieces)
Customized packaging (Min. Order: 1 Pieces)

More

Graphic customization (Min. Order: 1 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Model Number:
FHB397-H
Phase:
3, Three Phase
Type:
Hybrid
Certification:
CE
Current / Phase:
1.75A
Usage:
Universal
Protect Feature:
Enclosed
Function:
Control
Structure:
Synchronous Motor
Speed:
Variable Speed
Power:
AC
Shape:
Square
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Packed in plywood case or carton
Port
China
Picture Example:
package-img
Lead Time :
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 5 To be negotiated
Video Description



85mm 2Nm hybrid step motor is a brushless, synchronous electric motor that can divide a full rotation into a large number of steps. The motors position can be controlled precisely, without any feedfack mechanism. Choice of motor shaft length, single or double shaft, optical encoder and planetary gearbox are available for most motors.



Step Angle Accuracy: ±5%(full step, no load)
Temperature Rise: 80°C Max
Ambient Temperature:  -20°C ~ +50°C
Insulation Resistance: 100M Ω Min.500VDC
Dielectric Strength: 500V AC for one minute
Shaft Radial Play: 0.06mm Max.(450g-load)
Shaft Axial Play: 0.08mm Max.(450g-load)



Specifications:



Model

FHB397-H

Step Angle°

1.2

Length Lmm

69

Holding torque N.m

2

Current A

1.75

Rotor inertiag.c

1320

Weight kg

2

shaft diametermm

12

shaft extensionmm

feather key 4 * 20





For more information, please contact us freely.



We can design according to clients' requirement.



FHB397-H detail drawing



86
