servo motor system controller 1kw 2500ppr

FOB Reference Price:Get Latest Price
$295.00 - $345.00 / Piece | 1 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Lead Time:
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 5 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Model Number:
80ST-M04025 and MG1000C-30L
Type:
Servo Motor
Frequency:
50 hz
Output Power:
1 kw
Protect Feature:
Drip-proof
Phase:
Three-phase
Certification:
CE
AC Voltage:
208-230 / 240 V
Efficiency:
IE 3
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
packed in carton or plywood case
Port
China
Lead Time :
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 5 To be negotiated

Servo motor system controlle 1kw 2500ppr has a very compact structure and attractive appearance. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance.



They are widely used in digit control machine tools, laser processing machines, computer embroidery machines, textile machinery, printing machinery, packaging machinery, markers, engraving machines, winding machines, three-coordinates measuring machines, XYZ three- dimensional tables, industrial robots, medical equipment, woodworking machinery, ceramic machinery and other industries.



Motor model

80ST-M04025

Rated power(kw)

1.0

Rated current(A)

4.4

rated speed(rpm)

2500

Rated torque(N.m)

4

Peak torque(N.m)

12

Voltage constant (V/1000r/min)

56

Moment coefficient(N.m/A)

0.9

rotor inertia(Kg.m2)

3.5*10-4

Resistance line-line (Ω)

1.83

Inductance line-line(mH)

4.72

Electrical time constant(ms)

2.58

Encoder line(PPR)

2500

Pole-pairs

4

Weight(KG)

3.8

Insulation class

Class B (130 degree)

Grade of Protection

IP65

The operating of Evironmental conditions

Temperature

-20 ~ +  50 degree

Humidity

Below 90%RH No dewing

Environment

Far away active gas,combustible gas, oil drop,ash.





Please contact with us for more detailed technical information



We can design according to clients' requirements.

 80ST-M04025 Detail DrawingEP1 and EP2 driver connection



80mm and 90mm parts 180mm and 90mm parts 280mm and 90mm parts 380mm and 90mm rotor80mm and 90mm parts 5
