200w servo kits 60mm 3000rpm

FOB Reference Price:Get Latest Price
$275.00 - $345.00 / Pieces | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 5 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Model Number:
60CST-M00630 and MG1000C-20L
Output Power:
200w
Type:
Servo Motor
Frequency:
50 hz
Phase:
Three-phase
Certification:
CE
Protect Feature:
Drip-proof
AC Voltage:
208-230 / 240 V
Efficiency:
IE 3
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
packed in plywood case or carton
Port
China
Lead Time :
Quantity(Pieces) 1 - 50 >50
Est. Time(days) 5 To be negotiated

200w servo engines 60mm 3000rpm has a very compact structure and attractive appearance. The motor has some good features, such as high efficiency, energy-saving, high starting torque and easy maintenance.



They are widely used in digit control machine tools, laser processing machines, computer embroidery machines, textile machinery, printing machinery, packaging machinery, markers, engraving machines, winding machines, three-coordinates measuring machines, XYZ three- dimensional tables, industrial robots, medical equipment, woodworking machinery, ceramic machinery and other industries.



Specifications:



Motor model

60CST-M000630

Rated power(W)

200

Rated voltage(V)

220

Rated current(A)

1.5

Rated speed(rpm)

3000

Holding torque(N.m)

0.637

Peak torque(N.m)

1.911

Voltage constant(V/1000r/min)

28

Torque coefficient(N.m/A)

0.42

Rotor inertia(Kg.m)

0.17×10-4

Phase Resistance(Ω)

11.6

Phase Inductance(mH)

22

Machanical time-constant(Ms)

1.9

Weight(Kg)

1.11

Encoder line number(PPR)

2500

Insulation class

Class B(130 degree)

Safety class

IP64

The operating

of Evironmental Conditions

Temperature: -20 ~ +50 degree

Humidity: Below 90%RH No dewing

Motor winding

plue

Winding lead wire

U(red)

V(yellow)

W(blue)

PE(yellow, green/black)

Plug serial numberr

1

2

3

4

Encoder plug

Signal lead wire

5V

0V

B+

Z-

U+

Z+

U-

A+

V+

W+

V-

A-

B-

W-

PE

Plug serial number

2

3

4

5

6

7

8

9

10

11

12

13

14

15

1







Please contact with us for more detailed technical information.



We can design according to clients' requirements.
