hot nema34 bipolar step motor

FOB Reference Price:Get Latest Price
$24.00 - $39.00 / Pieces | 1 Piece/Pieces (Min. Order)
Model Number:
FHB86-80
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Usage:
Universal
Protect Feature:
Enclosed
Function:
Control
Structure:
Synchronous Motor
Phase:
Three Phase
Speed:
Variable Speed
Power:
DC
Shape:
Square
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Packed in Wooden box or Carton
Port
China

Hot nema 34 bipolar motor has such advantage as high efficiency, energy-saving, low noise, low vibration, "high start torque","low start current" and reliable performance. They are easy for installation and maintenance





Hot nema 34 bipolar motor bipolar motor specifications:



Model

FHB86-80

Step Angle(°)

1.8

Length L(mm)

80

Holding torque(N.m)

4.5

Current (A/phase)

4.2

Resistance(Ω)

0.8

Inductance (mH)

3.4

Rotor inertia (g.cm^2)

1400

Weight (kg)

2.3

Step accuracy

5%

Temperature

80degree  Max

Environmental temperature

-20degree ~  +50 degree

Insulation resistance

100MΩ   Min 500 V DC

Withstand voltage

500V AC 1minute

Shaft Radial Play

0.02mm Max.(450g-load)

Shaft Axial Play

0.08mm Max.(450g-load)

Shaft diameter (mm)

12.7

Shaft length (mm)

32



Please contact with us for more detailed technical information.



We can design according to clients' requirement.
