110mm 1200w waterproof servo motors

FOB Reference Price:Get Latest Price
$130.00 - $180.00 / Pieces | 1 Piece/Pieces (Min. Order)
Model Number:
110ST-M06020
Lead Time:
Quantity(Pieces) 1 - 20 >20
Est. Time(days) 7 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
MiGe
Usage:
Universal
Protect Feature:
Explosion-proof
Function:
Control
Structure:
Synchronous Motor
Phase:
Three Phase
Speed:
Variable Speed
Power:
AC
Shape:
Square
Supply Ability
Supply Ability:
50000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Packed in Wooden box or Carton
Port
China
Lead Time :
Quantity(Pieces) 1 - 20 >20
Est. Time(days) 7 To be negotiated

Electric motor 110mm has a very compact structure and attractive appearance. The motors have good features, such as high efficiency, energy-saving, high starting torque and easy maintenance.



They are mainly applied for machinery and equipment such as digit control machine tools, laser processing machines, computer embroidery machines, textile machinery, printing machinery, packaging machinery, markers, engraving machines, winding machines, three-coordinates measuring machines, XYZ three- dimensional tables, industrial robots, medical equipment, woodworking machinery, ceramic machinery and other industries.



Electric motor 110mm Specifications



Motor model

110ST-M06020

Rated power(kW)

1.2

Rated voltage(V)

220

Rated current(A)

4.5

Rated speed(rpm)

2000

Holding torque(N.m)

6

Peak torque(N.m)

12

Voltage constant(V/1000r/min)

83

Torque coefficient(N.m/A)

1.3

Rotor inertia(Kg.m)

0.76×10-4

Phase Resistance(Ω)

1.46

Phase Inductance(mH)

4.7

Machanical time-constant(Ms)

3.2

Weight(Kg)

6.7

Encoder line number(PPR)

2500

Insulation class

Class B(13 degree)

Safety class

IP64

The operating

of Evironmental Conditions

              Temperature: -20 ~ +50 degree

              Humidity:Below 90%RH No dewing

Motor winding

plue

Winding lead wire

U(red)

V(yellow)

W(blue)

PE(yellow, green/black)



Plug serial numberr

1

2

3

4



Encoder plug

Signal lead wire

5V

0V

B+

Z-

U+

Z+

U-

A+

V+

W+

V-

A-

B-

W-

PE

Plug serial number

2

3

4

5

6

7

8

9

10

11

12

13

14

15

1







Please contact with us for more detailed technical information.



We can design according to clients' requirement.
